Numerical Simulation: The Effect of Baffle Spacing on the Effectiveness of the Shell-and-Tube Type Heat Exchanger

Introduction

Heat exchange devices play a crucial role in various industries, facilitating heat exchange between two or more fluids with temperature differences. The shell-and-tube type heat exchanger is one of the most widely used types of heat exchange devices. This study aims to analyze the effect of baffle distance on fluid flow and the effectiveness of the shell-and-tube type heat exchange device using a numerical simulation approach.

The Importance of Heat Exchange Devices

Heat exchange devices are essential in various industries to maintain the sustainability and efficiency of the production process. They facilitate heat exchange between two or more fluids with temperature differences, which is critical in various applications, including power generation, chemical processing, and refrigeration. The shell-and-tube type heat exchanger is a popular choice due to its simplicity, reliability, and effectiveness.

The Role of Baffles in Heat Exchange Devices

Baffles are used in heat exchange devices to direct fluid flow and increase heat transfer between hot and cold fluids. The distance between baffles is a critical parameter that affects the performance of the heat exchanger. A shorter distance between baffles can produce more turbulent flow, thereby increasing the efficiency of heat exchange. However, a distance that is too small can also cause increased pressure and energy loss, which can affect the overall performance of the device.

Numerical Simulation Approach

This study uses Computational Fluid Dynamics (CFD) software to simulate the shell-and-tube heat exchange devices with various baffle distances of 40mm, 50mm, and 60mm. The conditions analyzed in the simulation are steady (steady) and laminar flow, with a heat fluid flow rate of 1.8 lpm and cold fluid of 10 lpm. The fluid used in this simulation is engine oil as a hot fluid and water as a cold fluid.

Simulation Results

The simulation results show the temperature distribution in the heat exchanger, and record the average temperature on the surface out of the tube and shell. The resulting temperature is then used to calculate the effectiveness of the heat exchanger. From the analysis conducted, the highest effectiveness of 65.18% was obtained at a 40mm baffle distance, with a hot fluid entry temperature of 60 ° C and cold fluid entry temperature 27 ° C. These findings indicate that the greater the distance of the baffle, the lower the effectiveness of the shell and tube heat exchanger used.

Additional Analysis and Explanation

The use of baffles in heat exchange devices aims to direct fluid flow and increase heat transfer between hot and cold fluids. Shorter distance of baffles can produce more turbulent flow, thereby increasing the efficiency of heat exchange. However, the distance of baffles that is too small can also cause increased pressure and energy loss, which in turn can affect the overall performance of the device.

From the results of the study, it can be concluded that the optimization of the distance of the baffle is very important in the design of the shell and tube type heat exchanger. In addition, the effectiveness of the heat exchanger can be influenced by various factors, including the entry temperature, the flow rate of the fluid, and the thermal nature of the fluid used. Therefore, it is important for engineers and researchers to consider all of these variables when designing heat exchange devices for industrial applications.

Benefits of Numerical Simulation

Numerical simulation using CFD also provides significant benefits because it allows more detailed analysis of flow behavior and temperature distribution without requiring expensive and time-consuming physical experiments. This allows the development of a more efficient and effective solution in the heat transfer system in the industry.

Conclusion

This research not only provides insight into the effect of baffle distance on the effectiveness of heat exchange devices, but also highlights the importance of the numerical simulation approach in the design and optimization of the heat exchange system. Going forward, further research is needed to explore other design variations and their effect on the performance of heat exchange devices, as well as to confirm these findings through practical experiments.
