Design and Realization of Dipole Dual Band Microstrip Antenna at 433 MHz and 2.4 GHz Frequency

Introduction

In the era of wireless communication, antennas play a crucial role in various systems, including cellular networks, Wi-Fi, and IoT systems. The demand for efficient and compact antennas has led to the development of dual band antennas, which operate at multiple frequencies. This study focuses on the design and realization of a dual band dipole microstrip antenna that operates at 433 MHz and 2.4 GHz frequencies.

Background

Antennas are essential components in wireless communication systems, and their design plays a significant role in determining the performance of the system. Dual band antennas, in particular, are designed to operate at two or more frequencies, making them ideal for applications that require simultaneous communication at multiple frequencies. The design of dual band antennas involves careful consideration of various parameters, including the substrate material, antenna configuration, and frequency bands.

Design and Realization

The dual band dipole microstrip antenna designed in this study uses FR4 substrates with a dielectric constant of 4.4 and a thickness of 1.6 mm. The simulation was carried out using AWR software, which produced a return value of -30.79 dB and -23.65 dB and VSWR 1,059 and 1,142 at each frequency. The measurement results showed returns loss -24.49 dB and -14.81 dB, VSWR 1.12 and 1.44, and ribbon width 87,717 MHz and 146,381 MHz for frequencies of 433 MHz and 2.4 GHz.

Substrate Options

The choice of substrate material is a critical aspect of antenna design. In this study, FR4 substrate was chosen due to its easily formed nature, relatively low cost, and suitable dielectric characteristics for the selected frequency application. FR4 substrate is a popular choice for antenna design due to its excellent electrical properties and ease of fabrication.

Dipole Configuration

The dipole microstrip antenna offers a simple and compact design, making it ideal for portable applications. This configuration also allows adjusting shapes and sizes for performance optimization. The dipole configuration is particularly useful for dual band antennas, as it enables the design of antennas that operate at multiple frequencies.

Simulation and Measurement Results

The simulation results showed a good agreement with the measurement results, with a difference of less than 5 dB in returns loss and VSWR. However, the difference between simulation results and measurements can occur due to several factors, such as component tolerance, environmental influence, and imperfections in the manufacturing process.

The Width of the Ribbon

The width of the ribbon is an important parameter in antenna design, as it affects the frequency response of the antenna. In this study, the measurement results showed a wider band width at a frequency of 2.4 GHz, indicating that the antenna is more tolerant of frequency variations in the band. This is useful for applications that require higher frequency tolerance.

Benefits

The dual band antenna designed in this study has several benefits, including:

Efficiency of Space Usage

Combining two frequency bands in one antenna allows a reduction in the size and complexity of the device. This is particularly useful for applications where space is limited, such as in IoT devices.

Multi-function Capability

This antenna can be used for various applications that operate at 433 MHz and 2.4 GHz frequencies, such as wireless sensors, remote control systems, and data communication.

A Reliable Performance

Optimized and validated antenna design through simulations and measurements produces reliable performance in various conditions.

Conclusion

This study succeeded in designing and realizing a dual band dipole microstrip antenna that operates at 433 MHz and 2.4 GHz frequencies. The simulation and measurement results show good performance, indicating that the design of this antenna can be applied to various wireless applications.

Future Work

Future work can focus on optimizing the design of the dual band antenna to improve its performance and reduce its size. Additionally, the study can be extended to design and realize dual band antennas for other frequency bands, such as 5G frequencies.

References

AWR software manual
FR4 substrate datasheet
Dipole microstrip antenna design manual

Appendix

Simulation results
Measurement results
Antenna design files
